Specifications
| Input | 1/4” phone Jack
|
| Input Impedance | 5.1 Megohms
|
| Preamp Gain | -6dB,0dB, +6dB
|
| Input Level | -25dBv to +3dBv (0.056Vrms to 1.414Vrms)
|
| High Pass Filter | 45Hz, 75Hz, 120Hz
|
| Notch | -20dB, sweepable from 40Hz to 300Hz 1/8 octave 85Hz |
| Output Level | -1.4dBv (0.848Vrms) Unbalanced
|
| Output Impedance | 470 Ohms
|
| DC Power Consumption | 43mW Max at 9V
|
| DC Current Draw | 4.5mA
|
| Voltage Range | 7.5VDC . 12VDC
|
| Power Supply | 9VDC with 100mA minimum
|
| 9V Battery Life | 110 hours
|
| Signal to Noise | 90dB
|
| Size | 82(w) x 64(H) x 130(D)mm
|
| Weight | 451g |
